GRANDE SERIES


COLOR
PUMP
  • NO PUMP
  • A.C. BOOSTER PUMP
  • D.C. SILENT PUMP
SHOWER SET
  • HAND SET
  • RAIN SHOWER SET

Category: A.C. Booster Pump, D.C. Silent Pump, Hand Shower Set, No Pump, Rain Shower Set

The exclusive instant water with powerful silent pump and rain shower to deliver to you unlimited hot shower water flow for a luxurious shower experience.

custom-icon
Multi-Spray Hand Set

Shower Hand Set selection allows users to select preferred shower spray pattern for optimum shower sensation.

custom-icon
Built-in AC Booster Pump / DC Silent Pump (optional)

Boosting shower water flow as much as 4.5 times for bathrooms that do not have enough water pressure.

custom-icon
Stepless Electronic Control

Allows users to make fine power adjustment to produce desired shower temperature.

custom-icon
Splash-Proof Casing

Protection against water jet spray from all possible directions.

custom-icon
Built-in RCD

Life-saving device which cuts off power supply in the event of current leakage, protecting users from getting electric shock.

custom-icon
Built-in Voltage Surge Protector

Protects internal electrical circuit from electrical surges and voltage spikes, including those caused by lightning.

custom-icon
Built-in Flow Sensor

Cuts off power supply in the event where water flow is less than the rated flow that might result in internal overheating.

custom-icon
Double Function Thermostat

Additional manual reset function in the event of abnormal temperature rise, protecting users from the risk of scalding.

custom-icon
UK Technology Heating Element

Advanced heating technology providing users with instant hot shower water flow, with a guaranteed 5-year warranty.

custom-icon
Unlimited Capacity Hot Water Supply

Tankless instantaneous water heater technology provides on-demand constant supply of hot water instantly without the need of waiting.

custom-icon
Pop-Start Regulated Stop Valve

Switch on both the water supply and water heater in just a tap, with the flow rate preset to your previous usage. No knob turning needed.

SHOWER WATER PUMP | BOOST YOUR BATH

Enhance your daily shower experience by equipping your GRANDE SERIES with the powerful CENTON Shower Water Pump:

A.C. Booster Pump

Cost efficient. Boosting water flow up to 4.5 times, this powerful build-in booster pump comes with speed control feature that allows you to control the volume of unlimited hot shower water flow.

D.C. Silent Pump

D.C. Silent Pump | Silent yet powerful. This built-in silent pump comes with the advanced 3-phase brushless DC motor that generate high flow rate and consumes 50% lower electrical power than normal AC motor.

SHOWER HAND SET | BE IN CONTROL

GRANDE SERIES comes with a 5-Spray Hand Set, to deliver to you adjustable spray heights, directions, modes and functions.

OR
Optionally, choose to upgrade to the Rain Shower Set for a more luxurious shower experience!

TECHNICAL SPECIFICATION

Heater Electrical Rating 3kW-8kW,220V-240Vac,50/60Hz
Minimum Water Flow Rate 2 litre / min
Maximum Water Pressure Plastic Tank :0.38MPa(3.8bar/55psi)
Copper Tank :0.60MPa(6bar/87psi)
Water Temperature Contro Electronic Control
Water Connection 15mm dia. (1/2″ BSP)
Dimensions 283mm x 630mm x 100mm (H)
Weight(Gross) No Pump : 3.1kgs
AC Pump : 4.1kgs
DC Pump : 3.6kgs
AC Pump Electrical Rating (Motor) 120W, 220V – 240Vac
DC Pump Electrical Rating (Motor) 50W, 24Vdc
