VINTAGE SERIES

Home Our Products VINTAGE SERIES

VINTAGE SERIES

COLOR
PUMP
  • NO PUMP
  • A.C. BOOSTER PUMP
SHOWER SET
  • HAND SET
  • RAIN SHOWER SET

Category: A.C. Booster Pump, Hand Shower Set, No Pump, Rain Shower set

Luxury, style, innovation, powerful yet silent water heater booster pump and advanced mechatronic RCD built into the heart of the heating system of Centon’s flagship shower water heater. To provide you with sensational showers with maximum safety from electrical hazard.

custom-icon
Multi-Spray Hand Set

Shower Hand Set selection allows users to select preferred shower spray pattern for optimum shower sensation.

custom-icon
Stepless Electronic Control

Allows users to make fine power adjustment to produce desired shower temperature.

custom-icon
Pop-Start Regulated Stop Valve

Switch on both the water supply and water heater in just a tap, with the flow rate preset to your previous usage. No knob turning needed.

custom-icon
Splash-Proof Casing

Protection against water jet spray from all possible directions.

custom-icon
Built-in RCD

Life-saving device which cuts off power supply in the event of current leakage, protecting users from getting electric shock.

custom-icon
Built-in Voltage Surge Protector

Protects internal electrical circuit from electrical surges and voltage spikes, including those caused by lightning.

custom-icon
Built-in Flow Sensor

Cuts off power supply in the event where water flow is less than the rated flow that might result in internal overheating.

custom-icon
Double Function Thermostat

Additional manual reset function in the event of abnormal temperature rise, protecting users from the risk of scalding.

custom-icon
UK Technology Heating Element

Advanced heating technology providing users with instant hot shower water flow, with a guaranteed 5-year warranty.

custom-icon
Unlimited Capacity Hot Water Supply

Tankless instantaneous water heater technology provides on-demand constant supply of hot water instantly without the need of waiting.

custom-icon
Built-in AC Booster Pump (optional)

Boosting shower water flow as much as 4.5 times for bathrooms that do not have enough water pressure.

SHOWER HAND SET | BE IN CONTROL

Enhance your daily shower experience by equipping your VINTAGE SERIES with the powerful CENTON Shower Water Pump:

A.C. Booster Pump | Cost efficient. Boosting water flow up to 4.5 times, this powerful built-in booster pump comes with speed control feature that allows you to control the volume of unlimited hot shower water flow.

SHOWER HAND SET | BE IN CONTROL

VINTAGE SERIES comes with a set of Aqualani 5-Spray Hand Set, to deliver to you adjustable spray heights, directions, modes and functions.

OR

Optionally, choose to upgrade to the Rain Shower Set for a more luxurious shower experience!

TECHNICAL SPECIFICATION

Heater Electrical Rating No Pump : 3.6kW
With Pump : 3.72kW
With Rain Shower + Pump : 4.2kW
220V-240Vac,50/60Hz
Minimum Water Flow Rate 2 litre / min
Maximum Water Pressure 3.87kg f/cm² / 380kPa (55psi)
Water Temperature Contro Electronic Control
Water Connection 15mm dia. (1/2″ BSP)
Dimensions 241mm x 386mm x 99mm (H)
Weight No Pump : 1.5kg
AC Pump : 2.5kg
DC Pump : 2.0kg
Rain Shower : + 1.5kg
AC Pump Electrical Rating (Motor) 120W, 220V – 240Vac
DC Pump Electrical Rating (Motor) 50W, 24Vdc
